OsramBack-LitLatticeLEDStrip-TaionLEDLighting

LED Rigid Bar/

Osram Back-Lit Lattice LED Strip

  • STH-F24P600W1L06B50
  • Product ID: 6W OSRAM LED Back-Lit Strip
  • LED Chip: high quality 2835 LED Osram
  • Lumens:720LM/PCS
  • Lens:  optical lens processing 175degrees
  • Material: Aluminum PCB & Silicone glue IP67
  • High efficacy up to 120lm/W
  • CE RoHS approved

  • Product Details
  • Osram Non-Waterproof Strips (available)

Osram 6W Back-Lit LED Rigid Strip For single-sided Light boxes

Product name: Osram Back-Lit LED Rigid StripApplication:For Single-side Slim sign box illumination
LED type: OSRAM SMD2835 LEDs 1.0WattLED quantity: 6pcs
Physical dimension:485mm (L)*21.5mm (W)*11.5mm (H)Operating voltage: 24VDC
Storage Temperature:-50℃~80℃Color Rendering Index (CRI): 80
Power consumption: 6W/PCSOperating temperature:  -40℃~60℃
Emitting color: Pure White/ Warm WhiteLuminous output each color:720LM/pcs
Beam angle: 175ºLife span: 50000 Hours
Protection grade: IP67Driven mode: Constant voltage
Weight:0.1KGPackage: 400pcs per inner carton, 2 cartons in 1 box
Quantity to illuminate each  evenly:  4pcsMaterial: Silicone Glue & Aluminum PCB
Depth/Thickness of Signs:  6~12cm
